WS2812 Addressable RGB LED Strip DC5V/DC12V | Dream Color Lighting

Programmable and customizable

ZBL Lighting introduced the WS2812 addressable RGB LED strip to meet the growing demand for precise pixel-level control and flexible installation in modern lighting projects. Each LED integrates a WS2812 IC, enabling individually addressable pixels for rich, dynamic color and animation effects. The flexible strip design easily adapts to curves, decorative elements, and various installation scenarios, making it ideal for signage, exhibitions, gaming rooms, stage setups, and architectural lighting. With low-voltage DC5V operation and reliable build quality, it ensures safe, straightforward installation and consistent performance over short to medium-length runs. This product combines visual impact, engineering reliability, and installation flexibility, empowering designers and engineers to create compelling, professional lighting solutions.

Get a quote +86 18923408595 info@zbl-lighting.com

Technical Information

Item	Specification
Product Name	WS2812 Addressable RGB LED Strip
LED Type	SMD 5050 RGB LED with Built-in WS2812 IC
Control Type	Individually Addressable (1 LED = 1 Pixel)
Operating Voltage	DC 5V
Signal Type	Single Data Signal
LED Density	30 / 60 / 144 LEDs per meter (optional)
Pixel Resolution	1 IC per LED
Power Consumption	18 W/m (60 LEDs/m)
Color Output	RGB Dream Color
Color Depth	8-bit per color, 24-bit color
Beam Angle	120°
PCB Type	Flexible FPCB
PCB Width	10 mm / 12 mm (optional)
Cutting Unit	Every 1 LED
Standard Length	5 m per reel (custom length available)
IP Rating	IP20 / IP65 / IP67 (optional)
Operating Temperature	–20°C to +50°C
Lifespan	≥30,000 hours
Dimmable	Yes (via controller)
Certifications	CE, RoHS
Compatible Controllers	WS2812, SPI, Arduino, ESP32, Pixel Controllers
Applications	Decorative lighting, signage, gaming rooms, stage lighting, creative installations
