High Quality OEM/ODM LED Strip Manufacturer

30° Lens Optical Design, Ultra Uniform Wall Washing Effect

In architectural lighting projects, traditional LED strips often fail to deliver true wall-washing performance due to insufficient optical control, uneven light distribution, and poor outdoor durability. Many solutions rely on simple linear light emission, which results in light spill, hotspots, and limited visual depth on building façades.
ZBL developed this Flexible Wall Washer LED Strip to solve these engineering limitations at the system level. By integrating a 30° precision lens structure with high-density 48LEDs/m SMD2835 configuration, the product transforms standard linear lighting into controlled directional wall illumination. Combined with IP67 waterproof silicone protection, it ensures stable performance in long-term outdoor and architectural applications.
This product was engineered for professional lighting designers and contractors who require not just brightness, but optical accuracy, installation reliability, and consistent façade lighting performance in real-world projects.
| Parameter | Specification |
|---|---|
| Product Name | Flexible Wall Washer LED Strip |
| LED Type | SMD2835 |
| LED Quantity | 48 LEDs/m |
| Power Consumption | 16W/m |
| Beam Angle | 30° Lens Optical |
| CCT | 2700K Warm White |
| Voltage | DC24V |
| PCB Width | 15mm |
| Waterproof Rating | IP67 |
| Cutting Step | 20.83mm |
| Cable | 2-pin waterproof cable, 20cm on both sides |
| Length | 5m/roll or customized |
| Mounting | 3M VHB adhesive |
| Operating Temperature | -20°C to +60°C |
| Application | Wall washing, façade lighting, architecture, landscape, commercial projects |
| Warranty | 3 years |
