48V mining strip · up to 240 m reference run · 810 lm/m · IP67
A high-voltage DC strip designed for very long underground routes where minimizing feed points and conductor losses is a primary requirement. The 48V circuit, 9W/m load and 48 LED/m configuration support extended linear installations with lower current than comparable lower-voltage products.
Its distinguishing feature is the published reference run of up to 240 m when used with the correct supply, cable and feed arrangement. The SMD2835 platform, CRI above 80 and -20°C to 55°C operating range make it the most project-focused long-distance mining option in this group.
Choose it for long mine routes, decline access, conveyor corridors and infrastructure runs. ZBL must validate the complete circuit before the maximum length is used in a specification.
Send the route length, supply locations, mounting height, ambient conditions and destination market. ZBL will confirm the electrical layout, construction, documentation and sample plan for the selected version.
Compare more SMD LED strip options, review our guide to choosing the right LED strip, and explore residential lighting applications.
| Nominal voltage | 48V DC |
| Light output | 810 lm/m |
| Power | 9 W/m |
| Luminous efficacy | 90 lm/W |
| LED configuration | 48 SMD2835 LEDs/m |
| Color temperature | 6500K standard; green project variant available |
| CRI | >80 for white version |
| Maximum reference run | Up to 240 m with approved power and feed design |
| Recommended mounting height | 5–6 m |
| Ambient operating range | -20°C to 55°C |
| Reference illuminance | 67.5 lx average at 2 m in a 3 m × 3 m tunnel model |
| Ingress protection | IP67 |
| Power-system protection | Short circuit, overvoltage, overtemperature and overcurrent protection |
| Design service life | Up to 10 years, subject to operating hours, ambient temperature, power quality and installation conditions |
| Product warranty | 5 years, subject to approved specification and warranty terms |
| Customization | Cut length, cable exit, connector, light output, color and project packaging |
